FEATURES & CAPABILITIES:
• Longitudinal on V-flat scraped guideways
• Column traveling crossfeed
• Motorized rapid elevation
• Spindle motor frequency inverter *Optional
• Hydraulic oil chiller *Optional
• Full enclosure *Optional
• Overhead hydraulic wheel dresser
• Variable spindle speed *Optional
• Surface grinding
• Plunge grinding
Main Specifications
Capacity
Overall table working area: 24"x60"
Longitudinal table travel: 63"
Crossfeed table travel: 26"
Distance spindle center to table: 23.6"
Grinding Wheel
Wheel dimension (Dia. x W x Bore): 14" or 16"x2"x5"
Spindle speed: 1740 RPM
Vertical Movement
Vertical on MPG / Handwheel 1 gra: 0.0001"
Vertical on MPG / Handwheel 1 rev: 0.02"
Auto downfeed increment: 0.0002-0.0016"
Motor
Spindle motor: 10HP (15 HP Optional)
Dimension & Weight
Machine height: 94"
Floor space: 228"x96"
Net weight: 13750 lbs.
Gross weight: 15950 lbs.
Standard Equipment
*460V
Front Table Splash Guard
Three Axis Automatic
Electro Magnetic Chuck
M4 Coolant System with Magnetic Seperator & Paper Filter
Grinding Wheel Flange
Flange Removal Tool
Balance Table
Balance Rod
Grinding Wheel 355x50x127mm
Tool Set
Machine-to-adjust-Sizing-Block
Complete Documentation
