New MILLUTENSIL AM 04 | Die-splitters

Description

The first model for small and medium dies.

The AM 04 is the first model with an hydraulic system controlled by electronic servo proportional valves and a control of parallelism. The control system includes measurement devices. They are integrated in the brushless engines and continuously check the die splitter upper plate position and parallelism compared to the lower plate. The die-splitter is monitored through Siemens PLC commanded by Touch Panel.
Platen dimensions are 1400×1070 mm (55×42 inches).
The max. clamping force is 60 kN.
The max. load capacity on lower plate is 4.000 kg, while on the upper is 1.500 kg.
As all series, the AM 04 can also be equipped with all optional accessories.
