YCM B7G High Precision Graphite Machining Center
Have one to sell?
ConditionNew
New
The B series vertical machining centers deliver high-caliber precision machining providing superb cutting ability with reduced vibration. The B series is built with a box shaped double column structure which ensures the highest level of stability during high-speed movement. Every machine is built and handcrafted for rigidity, thermal stability, and repeatability.
• Travels: X 25.98” x 20.08” x 15.75"
• 30,000 RPM Spindle
• Dual Contact HSK40E
• 20T ATC
• Cutting Air Blast
• Spindle Air Blast
• Spindle Air Seal (Labyrinth)
• 4 - Standard M-Codes
• Spindle Cooling System
• Air Gun
• Interior Work Light
• 3-Color Status Light
• Automatic Power Off
• Interlocking Door Safety Switch
• Central Auto-Oil Lubrication System
• Guideway Covers on X/Y/Z
• Full Chip Enclosure
• Leveling Blocks and Bolts
• Heat Exchanger for Electrical Cabinet
• Mechanical, Electrical & Operating Manuals (CD)
• Tool Kit
